Getting Started with EJB

Mô tả tài liệu
  Download Vui lòng tải xuống để xem tài liệu đầy đủ

Setting up J2EE 1. 2. Install J2EE Set up enviroment variables JAVA_HOME J2EE_HOME CLASSPATH=.;%J2EE_HOME%\lib\j2ee.jar;%CLASSPATH % Set up shortcut to start j2ee and deploytool in Editplus j2ee –verbose deploytool 3. Getting Started with EJB &

Chủ đề:
Lưu

Nội dung Text: Getting Started with EJB

  1. Setting up J2EE 1. Install J2EE 2. Set up enviroment variables JAVA_HOME J2EE_HOME CLASSPATH=.;%J2EE_HOME%\lib\j2ee.jar;%CLASSPATH % 3. Set up shortcut to start j2ee and deploytool in Editplus j2ee –verbose deploytool Getting Started with EJB & J2EE 1. Creating the Enterprise Bean The enterprise bean in our example is a stateless session bean called ConverterEJB. The source code for ConverterEJB is in the ../converter directory To prepare, you should compile the remote interface (Converter.java), home interface (ConverterHome.java), and the enterprise bean class (ConverterBean.java). 2. Starting the J2EE Server To launch the J2EE server, open a terminal window and type this command: (should use shortcut in Editplus) j2ee –verbose 3. Starting the deploytool: (should use shortcut in Editplus) deploytool 4. Creating the J2EE Application • In deploytool, select File-> New-> Application. • Click Browse. • In the file chooser, navigate to folder ../converter. • In the File Name field, enter ConverterApp.ear. • Click New Application. • Click OK. 5. Packaging the Enterprise Bean To start the New Enterprise Bean wizard, select File->New->Enterprise Bean. The wizard displays the following dialog boxes. 1. Introduction dialog box a. Read the explanatory text for an overview of the wizard's features. b. Click Next.
  2. 2. EJB JAR dialog box a. Select the Create New JAR File In Application button. b. In the combo box, select ConverterApp. c. In the JAR Display Name field, enter ConverterJAR. d. Click Edit. e. In the tree under Available Files, locate the /converter directory. Select the following classes from the Available Files tree and click Add: Converter.class, ConverterBean.class, and ConverterHome.class. Click OK. f. Click Next. 3. General dialog box a. Under Bean Type, select the Session radio button. b. Select the Stateless radio button. c. In the Enterprise Bean Class combo box, select ConverterBean. d. In the Enterprise Bean Name field, enter ConverterEJB. e. In the Remote Home Interface combo box, select ConverterHome. f. In the Remote Interface combo box, select Converter. g. Click Next. 1. Transaction Management dialog box a. Because you may skip the remaining dialog boxes, click Finish. 6. Creating the Web Client The Web client is contained in the JSP page ../converter/index.jsp 7. Packaging the Web Client To start the New Web Component wizard, select File->New->Web Component. The wizard displays the following dialog boxes. 1. Introduction dialog box a. Read the explanatory text for an overview of the wizard's features. b. Click Next. 2. WAR File dialog box a. Select Create New WAR File In Application. b. In the combo box, select ConverterApp. c. In the WAR Display Name field, enter ConverterWAR. d. Click Edit. e. In the tree under Available Files, locate the /converter directory. f. Select index.jsp and click Add. g. Select Converter.class and click Add
  3. h. Select ConverterHome.class and click Add i. Click OK. j. Click Next. 3. Choose Component Type dialog box a. Select the JSP radio button. b. Click Next. 4. Component General Properties dialog box a. In the JSP Filename combo box, select index.jsp. b. Click Finish. 8. Specifying the Web Client's Enterprise Bean Reference When invoking the lookup method, the Web client refers to the home of an enterprise bean: Object objRef = ic.lookup("java:comp/env/ejb/MyConverter"); You specify this reference as follows: • In the tree, select ConverterWAR. • Select the EJB Refs tab. • Click Add. • In the Coded Name column, enter ejb/MyConverter. Rất mong được sự quan tâm thông cảm của Thầy giáo. Em xin chân thành cảm ơn thầy! Thưa thầy em cho dù đã rất cố gắng nhưng bài tập vẫn còn rất nhiều thiếu xót do chưa hiểu rõ bản chất của công nghệ. theo những hướng dẫn và sử dụng mã nguồn của thầy giáo(nhưng do nhiều lí do nên việc đóng gói chưa thể hoàn thiện). • In the Type column, select Session. • In the Interfaces column, select Remote. • In the Home Interface column, enter ConverterHome. • In the Local/Remote Interface column, enter Converter. 9. Specifying the JNDI Names Although the Web client refers to EJB as ejb/TheConverter, for the lookup method to retrieve the home object, you must map the references in the code to the enterprise bean's JNDI name. Although this mapping adds a level of indirection, it decouples the clients from the beans, making it easier to assemble applications from J2EE components To map the enterprise bean references in the clients to the JNDI name of the bean, follow these steps. 1. In the tree, select ConverterApp. 2. Select the JNDI Names tab. 3. To specify a JNDI name for the bean, in the Application table locate the ConverterEJB component and enter MyConverter in the JNDI Name column.
  4. 4. To map the references, in the References table enter MyConverter in the JNDI Name for each row 10. Deploying the J2EE Application 1. Select the ConverterApp application. 2. Select Tools Deploy. 3. In the Introduction dialog box, confirm that ConverterApp is shown for the Object To Deploy and that localhost is shown for the Target Server. 7. In the JNDI Names dialog box, verify the names you entered in the previous section. 8. Click Next. 9. In the WAR Context Root dialog box, enter converter in the Context Root field. When you run the Web client, the converter context root will be part of the URL. 10. Click Next. 11. In the Review dialog box, click Finish. 12. In the Deployment Progress dialog box, click OK when the deployment completes. 11. Running the Web Client To run the Web client, point your browser at the following URL: http://localhost:8000/converter
