MINISTRY OF EDUCATION MINISTRY OF HEALTH
HANOI MEDICAL UNIVERSITY
NGUYEN THI DUYEN
RESEARCH ON HYPERTROPHIC CARDIOMYOPATHY
AND CARDIAC FUNCTION BY ULTRASOUND
IN FETUSES OF DIABETIC MOTHERS
Specialzation : Cardiologist
Code : 62720141
SUMMARY OF THESIS
HA NOI - 2020
THE DISSERTATION WAS COMPLETED IN HANOI
MEDICAL UNIVERSITY
Scientific supervisor:
Assoc. Prof. MD. Truong Thanh Huong
Scientific supervisor 1: Associate Professor. PHAM HUU HOA
Scientific supervisor 2: Associate Professor. PHAM BA NHA
Scientific supervisor 3: Associate Professor. DINH THI THU HUONG
The thesis will be defended in front of The Council for Philosophy
Doctor in Medicine at Ha Noi University
At….. hour day month 2020
The thesis can be found at:
- The National Library
- Ha Noi Medical Library
1
INTRODUCTION
The urgency of the topic
Hypertrophic cardiomyopathy (HCM) and cardiac dysfunction in fetuses of
diabetic mother accounts for 15% of fetal cardiomyopathy, increasing perinatal
mortality by 3%, accounting for 15% of causes general death. However, this is also
one of the rare fetal cardiomyopathy that can be recovered if detected early and
treated promptly. Pre-pregnancy diabetes and uncontrolled diabetes have been
shown to increase the incidence of this disease in the fetus. But if a diabetic mother
is accompanied by obesity, over-weight gain during pregnancy or having fetal
macrosomia could increase the risk of fetal HCM, and how does the HCM affect to
fetal postpartum outcomes are issues that have not been clarified yet. At the
Department of Endocrinology-Diabetes of Bach Mai Hospital, a large number of
diabetic mothers are examined and treated, even though there is a multidisciplinary
combination with extensive experience in managing diabetes in pregnancy, but still
encounter many difficulties in controlling postpartum events in the fetus. With the
trend of developing fetal echocardiography (FE) applications in evaluating fetal
cardiac function and also stemming from practical needs on the subject, we
performed the topic "Research on hypertrophic myocardiopathy and cardiac
function by ultrasound in fetuses of diabetic mothers" with the desire to learn
more about what is left unanswered. The study was conducted with the following
two objectives:
1. To determine the prevalence, characteristics of hypertrophic
cardiomyopathy and cardiac function in fetuses of diabetic mothers.
2. To survey on some factors of mother and fetus related to fetal hypertrophic
cardiomyopathy.
New conclusions of the thesis
1. This is the first study in Vietnam determine the prevalence, characteristics
of hypertrophic cardiomyopathy and cardiac function in fetuses of diabetic
mothers and survey on some factors of mother and fetus related to fetal
hypertrophic cardiomyopathy. The descriptive longitudinal follow-up study on
511 pregnant women ensures rigorous scientificity and high reliability.
2. Diabetic mothers were accompanied by obesity, overweight gain during
pregnancy, fetus that "older than gestational age" could increase the risk of
developing HCM in the fetus and this HCM condition could increase the risk of
preterm birth, low birth weight, low 1 minute Apgar score less than 7. With
HbA1C value increased more than 6,1% could be predicted the occurrence of
HCM in the fetuses of diabetic mothers.
The composition of the thesis
The thesis consists of 128 pages, including: introduction 2 pages, overview
45 pages, research designs and methods 18 pages, results 24 pages, discussion 35
pages, conclusions 2 pages, recommendation 1 page, limitation of the thesis 1
page. The thesis consists of 23 tables, 19 charts, 36 pictures, 7 schematics, 159
references (16 Vietnamese documents and 143 English documents).
2
Chapter 1: OVERVIEW
1.1. Background of hypertrophic cardiomyopathy and cardiac dysfunction in
fetuses of diabetic mothers.
Diabetes in pregnancy is divided into 2 groups: pre-gestational diabetes and
gestational diabetes. According to the International Diabetes Federation,
Vietnam is one of the countries with the highest rates of diabetes in the world. In
addition, the prevalence of gestational diabetes increased significantly from 2,1
to 39% according to different diagnostic criteria. Diabetes in pregnancy has
many consequences for the mother and fetus. Fetal HCM due to diabtetic mother
is a common complication, accounting for about 33,3% of well-controlled
diabetic mothers and up to 75% in uncontrolled diabetic mothers. Fetal cardiac
dysfunction is also a frequent complication in these fetuses with mainly reduced
diastolic function at the rate of 15 - 40% and 5% systolic heart failure.
Fetal HCM related to diabetic pregnancy is an abnormal thickening of the
ventricular walls or interventricular septal (IVS) due to maternal hyperglycemia
without other cardiomyopathic etiologies in the fetus. Pathogenesis mechanisms
through four main pathways: increased fetal blood insulin, changes in the signaling
pathway to the target heart gene, overproduction of oxidative reagents and
increased fetal growth factors. Histopathological damage of fetal cardiomyopathy
due to diabetic mother is glycogen deposition, increases protein synthesis mainly
myosin, leading to an increase in myocardial cells size especially in IVS.
According to the recommendations of the American College of Cardiology and
the American Heart Association on the diagnosis of HCM, the diagnosis of fetal
HCM when the thickness of any cardiac walls or IVS is measured at the end of
diastole on time mode ultrasound is more than 2 time of standard deviations from
the mean of normal fetuses at the same gestational age. HCM in the fetus due to
diabetic mother has a number of specific characteristics such as: common in the
last 3 months of pregnancy, most hypertrophy of the IVS, the severity of
hypertrophy is usually moderate, less likely to obstruct the output of the ventricle,
may present transiently in the fetus and especially must occur in the fetus whose
mother was diagnosed with diabetes during pregnancy. Fetal cardiac dysfunction
due to diabetes is often discreet diastolic function. However, in order to diagnose
fetal anomaly in diabetic mother still need to eliminate other HCM etiologies in fetus,
so the diagnosis and monitoring after birth in these fetuses are very important.
1.2. Characteristic of structure and function of normal fetal heart and the role
of echocardiography in assessing fetal cardiac thickness and function.
The physiology of the fetal circulation is really different from after birth. The
fetal myocardium has inefficient contraction due to immature myocardial cells,
underdeveloped T-duct system, metabolism dependent on lactate metabolism
with low energy source, myocardium contains many protein components less
differentiated, large intracellular matrix makes fetal myocardium less dilated and
low elasticity, leading to reduced "inherent" physiological diastolic function in
the fetus. During pregnancy, fetal myocardial cells gradually improve in quality
and increase in size, reduce intracellular matrix, arrange and differentiate the
structure into a 3-layer pattern as in adulthood, thereby fetal cardiac function
gradually matures and improves. With the existence of internal and external
cardiac flows, the impact of preload and afterload on fetal cardiac performance is
also different from that of adulthood. Therefore, the assessment of fetal cardiac
function must be consistent with the development stage of the fetus.
3
Fetal echocardiography (FE) was introduced more than 50 years ago with the
first role of identifying heart defects. Nowadays, FE becomes more and more
useful in evaluating fetal heart function from an early stage, in order to minimize
fetal mortality. Most of the evaluation parameters for fetal cardaic function have
been widely used in children and adults such as quantifying the velocity of flow
through the heart valves, estimating the strock volume, cardiac output, velocity and
the teleport, deform into the heart. FE can overcome and supplement the
disadvantages of other techniques in evaluating fetal heart function but there are
also certain difficulties and must be adjusted according to gestational age.
1.3. Overview of studies on fetal HCM and cardiac dysfunction due to
diabetic mother
In the world, the first case of HCM was recorded in an infant of a diabetic
mother by Maron et al in 1937. Since 1992, many studies have presented the
prevalence, characteristics of HCM and cardiac dysfunction of fetuses due to
diabetic mother, and proving the relationship between this complication and type
of diabetic mother, the severity of maternal blood glucose, as well as the role of
glucose control in limiting this pathology in the fetus. However, there have been no
studies evaluating the impact of obesity and the excessive weight gain during
pregnancy on fetal HCM and fetal cardiac dysfunction or its impact on postpartum
outcomes. In Vietnam, studies of FE in evaluation of cardiac function is still new.
Nowadays, the best FE study in our country was belonged to Le Kim Tuyen (2014)
on the role of FE in diagnosing congenital heart disease before birth. In the context,
the incidence of diabetic mother in our country is increasing. Many studies by local
authors have determined the prevalence of perinatal events of fetuses whose
mother has diabetes during pregnancy as well as the relationship with the mother's
severity of hyperglycemia. However, there have not been any studies evaluating
the association between fetal HCM and perinatal outcomes of these fetuses.
Chapter 2: RESEARCH DESIGNS AND METHODS
2.1. Subjects
2.1.1. Inclusion criteria and exclusion criteria
a. Inclusion criteria:
Pregnant women greater than or equal to 18 years of age at the time of the study,
Single pregnancy,
Natural pregnancy,
Pregnancy from 28 weeks or more,
Pregnant women agreed to participate in the study.
b. Exclusion criteria:
On the mother' side:
Having diseases that affect to glucose metabolism, acute and chronic diseases,
Using drugs that affect to glucose metabolism or fetal cardiac function,
Have pregnancy by intervention methods
On the fetus’ side:
Having basic prenatal mid-high risk screening tests,
Having abnormal structural heart: congenital heart disease, tumor,..
Having arrhythmias,
Fetal HCM due to other uterio etiologies,
Was still-borned at the time of study.
