Lecture 28
Recap Functions with No input OR No output Determining The Number of Input and Output Arguments Local Variables Global Variables Creating ToolBox of Functions Anonymous Functions and Function Handles Function Functions Subfunctions
Summary of Chapter MATLAB contains a wide variety of builtin functions However, you will often find it useful to create your own MATLAB functions The most common type of userdefined MATLAB function is the function Mfile, which must start with a functiondefinition line that contains the word function a variable that defines the function output a function name a variable used for the input argument
Continued…. The function name must also be the name of the Mfile in which the function is stored Function names follow the standard MATLAB naming rules Like the builtin functions, userdefined functions can accept multiple inputs and can return multiple results Comments immediately following the functiondefinition line can be accessed from the command window with the help command Variables defined within a function are local to that function. They are not stored in the workspace and cannot
Continued…. Groups of userdefined functions, called “toolboxes,” may be stored in a common directory and accessed by modifying the MATLAB® search path. This is accomplished interactively with the path tool, either from the menu bar, as in File > Set Path or from the command line, with pathtool MATLAB provides access to numerous toolboxes developed at The MathWorks or by the user community Another type of function is the anonymous function,
Chapter 13 Numerical Techniques
Introduction Interpolate between data points, using either linear or cubic spline models Model a set of data points as a polynomial Use the basic fitting tool Use the curvefitting toolbox Perform numerical differentiations Perform numerical integrations Solve differential equations numerically
Interpolation Especially when we measure things, we don’t gather data at every possible data point Consider a set of x–y data collected during an experiment By using an interpolation technique, we can estimate the value of y at values of x where we didn’t take measurement The two most common interpolation techniques are Linear interpolation Cubic spline interpolation
Interpolation between data points
Linear Interpolation The most common way to estimate a data point between two known points is linear interpolation In this technique, we assume that the function between the points can be estimated by a straight line drawn between them If we find the equation of a straight line defined by the two known points, we can find y for any value of x The closer together the points are, the more accurate our approximation is likely to be
Continued…. We can perform linear interpolation in MATLAB with the interp1 function We’ll first need to create a set of ordered pairs to use as input to the function The data used to create the righthand graph of next figure is x = 0:5; y = [15, 10, 9, 6, 2, 0];
Continued…. To perform a single interpolation, the input to interp1 is the x data, the y data, and the new x value for which you’d like an estimate of y For example: to estimate the value of y when x is equal to 3.5, type interp1(x,y,3.5) ans = 4 You can perform multiple interpolations all at the same time by putting a vector of x values in the third field of the interp1 function For example: to estimate y values for new x ’s spaced evenly from 0 to 5 by 0.2, type
Continued…. The interp1 function defaults to linear interpolation to make its estimates. However, other approaches are possible If we want (probably for documentation purposes) to explicitly define the approach used in interp1 as linear interpolation, we can specify it in a fourth field: interp1(x, y, 3.5, 'linear') ans = 4
