2.7 Create Stored Procedures
Stored procedures allow you to perform bulk operations on records, such as updating,
inserting, and deleting data as needed. This tutorial shows you how to create stored
procedures as well as how to test them from within the Server Explorer.
Viewing data is great, but you need to perform bulk operations such as adding, updating,
and deleting records. You know that you will be using a stored procedure to perform
these tasks, and you will be using them more than once in your application. How do you
create stored procedures from VS?
Stored procedures are the way to go when you want add, delete, or update records or
when you want to use a parameter. When you have a task that requires multiple actions,
including temporary tables, stored procedures give you this ability. Stored procedures are
powerful to use and easy to create.
To create stored procedures, you will use what is called Transact-SQL
(T-SQL). Although this chapter will present some simple commands to
show the interface used to create stored procedures from VS .NET,
Chapter 6, "Creating Transact-SQL Commands," goes into more detail
on the commands of the language.
As with views, you will use a designer within Visual Studio. Unlike the Views designer,
the stored procedure designer is not visual initially, but more text oriented. However, you
can pull up a visual designer after you are in the text designer.
When you're creating a new stored procedure, you will right-click on the Stored
Procedures node in the database to which you want to add the stored procedure, and then
you will choose New Stored Procedure. To edit existing stored procedures, you will
highlight the stored procedure, right-click, and choose Edit Stored Procedure.
After the stored procedure is open, you will see a select statement or a number of T-SQL
statements. If it is a new stored procedure, you can right-click and choose Insert SQL.
You will be taken to the Query Builder, which happens to look like the View designer. If
it is an existing stored procedure, you can place the cursor within a block of SQL code,
which is outlined with a blue line, and choose Design SQL Block from the right-click
menu, as shown in Figure 2.12.
Figure 2.12. You can also set break points in your stored procedures using this
You will then see the SQL block displayed once again in the Query Builder.
When specifying parameters that can be used as criteria in stored procedures, you will
use the @ symbol in front of the parameter name, and declare them at the top of your
stored procedure. Again, you can see this in Figure 2.12.
For this How-To, you are going to create a simple Select statement with a parameter,
listing customers for a given city. If you're not already there, open the Server Explorer
and expand the Northwind database.
1. Right-click on the Stored Procedures node, and then choose New Stored
Procedure. You will be taken into a new page that is a template for stored
procedure text. You will see the following listed:
2. CREATE PROCEDURE dbo.StoredProcedure1
5. @parameter1 datatype = default value,
6. @parameter2 datatype OUTPUT
10. /* SET NOCOUNT ON */
12. Replace all the text displayed with the following:
13. CREATE PROCEDURE dbo.spListCustomersForCountry
14. @parCountry char
16. Select * From Customers where Country = @parCountry
With this, you can see the use of the parameter.
18. Save the stored procedure.
How It Works
To test the stored procedure that you just created, you can right-click on the block of code
and choose Design SQL Block from the menu. You can then click on the Run Query
toolbar button and fill in the parCity parameter with USA when the dialog box is
presented. You will then see the information displayed in the Results pane.
You will see examples of using stored procedures in the next chapter, which discusses
using ADO.NET with SQL Server objects.
Although you can create stored procedures on-the-fly and not save them in the database,
it is sometimes necessary and desirable to save them permanently so that you can use the
same code in different places in your application.
