Circuit & Application Level Gateways
CS-431
Dick Steflik
Application Level Gateways
●Also called a Proxy Firewall
●Acts as a relay for application level traffic
−Typical applications:
●Telnet
●FTP
●SMTP
●HTTP
●More secure than packet filters
−Bad packets won't get through the gateway
−Only has to deal with application level packets
●Simplifies rules needed in packet filter
●Client connects
●Gateway does in depth inspection of the
application level packet, if connection meets
criteria on the gateway rule base packet will be
proxied to the server
●Proxy firewall is directly between the client and
the server on an application by application
basis
ALG Use
●Many application clients can be configured to
use a specific ALG (proxy) by the end user
−Firefox-Options-Advanced-Network-Connections-
Proxy
−WS/FTP-Connect-Firewall-Proxy
●Router can be set to forward all application
packets to specific proxy
−Benefit is all user traffic is forced to a proxy
−User cannot bypass the proxy
Additional ALG Benefits
●Privacy
−Outside world only sees the IP of the gateway not
the IPs of the end users
−Prevents foreign hosts from harvesting user
addresses for later use in SPAM
●Especially important for HTTP
●Ideal place to do logging
