  1. Chapter 19: Real-Time Systems Operating System Concepts – 8th Edition Operating System Concepts – 8th Edition 19.1 Silberschatz, Galvin and Gagne ©2009
  2. Chapter 19: Real-Time Systems s System Characteristics s Features of Real-Time Systems s Implementing Real-Time Operating Systems s Real-Time CPU Scheduling s An Example: VxWorks 5.x Operating System Concepts – 8th Edition 19.2 Silberschatz, Galvin and Gagne ©2009
  3. Objectives s To explain the timing requirements of real-time systems s To distinguish between hard and soft real-time systems s To discuss the defining characteristics of real-time systems s To describe scheduling algorithms for hard real-time systems Operating System Concepts – 8th Edition 19.3 Silberschatz, Galvin and Gagne ©2009
  4. Overview of Real-Time Systems s A real-time system requires that results be produced within a specified deadline period. s An embedded system is a computing device that is part of a larger system (i.e., automobile, airliner). s A safety-critical system is a real-time system with catastrophic results in case of failure. s A hard real-time system guarantees that real-time tasks be completed within their required deadlines. s A soft real-time system provides priority of real-time tasks over non real-time tasks. Operating System Concepts – 8th Edition 19.4 Silberschatz, Galvin and Gagne ©2009
  5. System Characteristics s Single purpose s Small size s Inexpensively mass-produced s Specific timing requirements Operating System Concepts – 8th Edition 19.5 Silberschatz, Galvin and Gagne ©2009
  6. System-on-a-Chip s Many real-time systems are designed using system-on-a-chip (SOC) strategy s SOC allows the CPU, memory, memory-management unit, and attached peripheral ports (i.e., USB) to be contained in a single integrated circuit Operating System Concepts – 8th Edition 19.6 Silberschatz, Galvin and Gagne ©2009
  7. Bus-Oriented System Operating System Concepts – 8th Edition 19.7 Silberschatz, Galvin and Gagne ©2009
  8. Features of Real-Time Kernels s Most real-time systems do not provide the features found in a standard desktop system s Reasons include q Real-time systems are typically single-purpose q Real-time systems often do not require interfacing with a user q Features found in a desktop PC require more substantial hardware that what is typically available in a real-time system Operating System Concepts – 8th Edition 19.8 Silberschatz, Galvin and Gagne ©2009
  9. Virtual Memory in Real-Time Systems s Address translation may occur via: 1. Real-addressing mode where programs generate actual addresses 2. Relocation register mode 3. Implementing full virtual memory Operating System Concepts – 8th Edition 19.9 Silberschatz, Galvin and Gagne ©2009
  10. Address Translation Operating System Concepts – 8th Edition 19.10 Silberschatz, Galvin and Gagne ©2009
  11. Implementing Real-Time Systems s In general, real-time operating systems must provide: 1. Preemptive, priority-based scheduling 2. Preemptive kernels 3. Latency must be minimized Operating System Concepts – 8th Edition 19.11 Silberschatz, Galvin and Gagne ©2009
  12. Minimizing Latency s Event latency is the amount of time from when an event occurs to when it is serviced. Operating System Concepts – 8th Edition 19.12 Silberschatz, Galvin and Gagne ©2009
  13. Interrupt Latency s Interrupt latency is the period of time from when an interrupt arrives at the CPU to when it is serviced Operating System Concepts – 8th Edition 19.13 Silberschatz, Galvin and Gagne ©2009
  14. Dispatch Latency s Dispatch latency is the amount of time required for the scheduler to stop one process and start another Operating System Concepts – 8th Edition 19.14 Silberschatz, Galvin and Gagne ©2009
  15. Real-Time CPU Scheduling s Periodic processes require the CPU at specified intervals (periods) s p is the duration of the period s d is the deadline by when the process must be serviced s t is the processing time Operating System Concepts – 8th Edition 19.15 Silberschatz, Galvin and Gagne ©2009
  16. Scheduling of tasks when P2 has a higher priority than P1 Operating System Concepts – 8th Edition 19.16 Silberschatz, Galvin and Gagne ©2009
  17. Rate Montonic Scheduling s A priority is assigned based on the inverse of its period s Shorter periods = higher priority; s Longer periods = lower priority s P1 is assigned a higher priority than P2. Operating System Concepts – 8th Edition 19.17 Silberschatz, Galvin and Gagne ©2009
  18. Missed Deadlines with Rate Monotonic Scheduling Operating System Concepts – 8th Edition 19.18 Silberschatz, Galvin and Gagne ©2009
  19. Earliest Deadline First Scheduling s Priorities are assigned according to deadlines: the earlier the deadline, the higher the priority; the later the deadline, the lower the priority Operating System Concepts – 8th Edition 19.19 Silberschatz, Galvin and Gagne ©2009
  20. Proportional Share Scheduling s T shares are allocated among all processes in the system s An application receives N shares where N < T s This ensures each application will receive N / T of the total processor time Operating System Concepts – 8th Edition 19.20 Silberschatz, Galvin and Gagne ©2009
