Sổ tay sửa chữa ô tô
KIẾN THỨC CƠ BẢN VỀ Ô TÔ
-1-
Khái quát
Cấu tạo ôtô
Xe ôtô bao gồm các bộ phận như sau:
1. Động cơ
• Động cơ xăng hoặc động cơ diesel
2. Hệ thống truyền lực
-2-
3. Gầm xe
• Hệ thống treo
• Hệ thống lái
• Hệ thống phanh
-3-
4. Điện động cơ
5. Điện thân xe
6. Thân vỏ
(1/1)
